MODEL INDOOR UNIT (240V / 1
OUTDOOR UNIT |
Phase / 50Hz) |
CS-HZ80YKR
[CU-HZ80YKR] |
||
Cooling / Heating | (min-max) | kW | 8.0 [2.3-9.0]
9.0 [2.2-11.8] |
|
Air Flow | Indoor | L/s | 367 | |
Star Rating Average Climate | Cooling Heating | 3.5 |
Dimensions | Indoor (HxWxD) | 295 x 1040 x 244
795 x 875 x 320 |
Outdoor (HxWXD) | ||
Refrigeration Pipe Diameter | Liquid Size | ø 1/4
ø 5/8 |
Gas Size |
Pipe Extension Length | min-max (m) | 3-30 | |
Maximum Elevation Length | m | 20 | |
Pipe Length For Additional Gas | m | 10 | |
Additional Gas Amount | g/m |
25 |
