MODEL INDOOR UNIT (240V / 1
OUTDOOR UNIT |
Phase / 50Hz) |
CS-HZ50YKR
[CU-HZ50YKR] |
||
Cooling / Heating ( | min-max) | kW | 5.00 [1.25-6.70]
6.00 [1.05-8.2] |
|
Air Flow | Indoor | L/s | 238 | |
Star Rating Average Climate | Cooling Heating | 4.5 |
Dimensions | Indoor (HxWxD) | 295 x 1040 x 244
619 x 824 x 299 |
Outdoor (HxWXD) | ||
Refrigeration Pipe Diameter | Liquid Size | ø 1/4
ø 1/2 |
Gas Size |
Pipe Extension Length | min-max (m) | 3~30 | |
Maximum Elevation Length | m | 15 | |
Pipe Length For Additional Gas | m | 10 | |
Additional Gas Amount | g/m |
15 |
