Aires Split Ducted Systems
ActronAir CRS10AS / EVA10AS 10.0kW Aires Split Ducted System – Single Phase
ActronAir CRS10AS / EVA10AS 10.00kW Split Ducted System – Single Phase
Indoor – Includes 8 Zone Integrated & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
ActronAir CRS13AS / EVA13AS 13.02 kW Aires Split Ducted System – Single Phase
ActronAir CRS13AS / EVA13AS 13.02kW Split Ducted System – Single Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL13R-2/35S – RETURN PLENUM – 2 x 350mm (14″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL18S-3/35S – SUPPLY PLENUM – 3 x 350mm (14″) spigot
- PL20S-3/SPS – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
ActronAir CRS13AT / EVA13AS 13.00 kW Aires Split Ducted System – Three Phase
ActronAir CRS13AT / EVA13AS 13.00kW Split Ducted System – Three Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL13R-2/35S – RETURN PLENUM – 2 x 350mm (14″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL18S-3/35S – SUPPLY PLENUM – 3 x 350mm (14″) spigot
- PL20S-3/35S – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
ActronAir CRS15AS / EVA15AS 15.40kW Aires Split Ducted System – Single Phase
ActronAir CRS15AS / EVA15AS 15.40 kW Split Ducted System – Single Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL18R-2/35S – RETURN PLENUM – 2 x 350mm (14″) spigot
- PL20R-2/40S – RETURN PLENUM – 2 x 400mm (16″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL18S-3/35S – SUPPLY PLENUM – 3 x 350mm (14″) spigot
- PL20S-3/SPS – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
Fully Installed ActronAir CRS15AS | EVA15AS | LR7-1W 15.40kW Aires Split Ducted System – Single Phase
ActronAir CRS15AS | EVA15AS | LR7-1W 15.40 kW Split Ducted System – Single Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Model: CRS15AS | EVA15AS | LR7-1W
- Based on Single Storey dwelling
- Installed by Licensed and Arctick Certified Installers
- Outdoor unit to be placed on Concrete slab | PVC Slab | PVC Mounting Blocks.
- Weatherproof isolator placed at outdoor.
- Use of PVC or Colourbond Ducts.
- Includes electrical circuit up to 15 metres.
- 5 years full manufacturer warranty on Parts and Labour.
- Sydney , Central Coast and Newcastle
*T and C Applies
ActronAir CRS15AT / EVA15AS 15.20 kW Aires Split Ducted System – Three Phase
ActronAir CRS15AT / EVA15AS 15.20 kW Split Ducted System – Three Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL13R-2/35S – RETURN PLENUM – 2 x 350mm (14″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL18S-3/35S – SUPPLY PLENUM – 3 x 350mm (14″) spigot
- PL20S-3/35S – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
ActronAir CRS17AS / EVA17AS 17.00 kW Aires Split Ducted System – Single Phase
ActronAir CRS17AS / EVA17AS 17.00kW Split Ducted System – Single Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL19R-2/40S – RETURN PLENUM – 2 x 400mm (16″) spigot
- PL19R-2/45S – RETURN PLENUM – 2 x 450mm (18″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL18S-3/35S – SUPPLY PLENUM – 3 x 350mm (14″) spigot
- PL20S-3/35S – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
ActronAir CRS17AT / EVA17AS 17.00 kW Aires Split Ducted System 3 Phase
ActronAir CRS17AT / EVA17AS 17.00 kW Split Ducted System – Three Phase
Includes 7 day wall controller (White/Grey) – 8 Zone & 20m CAT5E Cable – Yellow
Optional NEO Controller : NEO TOUCH Master Wall Controller (Black/White)
Optional available Supply Air Vbox:
- PL19R-2/40S – RETURN PLENUM – 2 x 400mm (16″) spigot
- PL19R-2/45S – RETURN PLENUM – 2 x 450mm (18″) spigot
- PL18S-2/35S – SUPPLY PLENUM – 2 x 350mm (14″) spigot
- PL20S-2/40S – SUPPLY PLENUM – 2 x 400mm (16″) spigot
- PL13S-3/30S – SUPPLY PLENUM – 3 x 300mm (12″) spigot
- PL20S-3/35S – SUPPLY PLENUM – 1 x 400mm (16″) / 2 x 350 (14″) spigot
AIRES Inverter split ducted systems, as well as their control and zoning options, are designed to support the way Australians genuinely live, providing greater comfort and energy savings. Enjoy year-round quality and comfort, as well as the peace of mind that comes with a durable and effective comfort solution.
Capacities: 1 Phase 10kW, 13kW, 15kW, 17kW. 3 Phase 13kW, 15kW, 17kW.
Compressor Inverter Twin Rotary. Operating Range -10ºC up to 50ºC
