MODEL INDOOR UNIT (240V / 1
OUTDOOR UNIT |
Phase / 50Hz) |
CS-HZ35YKR
[CU-HZ35YKR] |
||
Cooling / Heating ( | min-max) | kW | 3.50 [0.95-3.70]
4.10 [0.90-4.80] |
|
Air Flow | Indoor | L/s | 232 | |
Star Rating Average Climate | 5.0 |
Net Weight Indoor / Outdoor | 8/25 | |
Dimensions | Indoor (HxWxD) | 295 x 870 x 229
542 x 780 x 289 |
Outdoor (HxWXD) | ||
Refrigeration Pipe Diameter | Liquid Size | ø 6.35 (1/4)
ø 9.52 (3/8) |
Gas Size |
Pipe Extension Length | min-max (m) | 3~20 | |
Maximum Elevation Length | m | 15 | |
Pipe Length For Additional Gas | m | 7.5 | |
Additional Gas Amount | g/m |
10 |
