All information and tools provided by AirConditioning-online.com.au on our website is a guide to assist you. It does not, and is not intended, to replace the advice of a qualified HVAC engineer. Please use the following information and tools in good faith in preparation to speaking to a qualified engineer.
Location Dimensions
(in Metres) (Note: 1 Metre = 3.28 Feet)Total Volume
A.C. Required (for 0.00 M3)
Air Conditioning Sizing Chart
A Class |
B Class |
Insulated roof space, walls and sub floor, full brick or brick veneer construction, average size windows with awnings, full shading south facing aspect, temperate weather conditions. | Insulated roof space, full brick or brick veneer construction, average size windows with internal shades, north facing aspect, temperate climate. |
C Class |
D Class |
Insulated roof space, full brick or brick veneer construction, average size windows with internal shades, east facing aspect or sub tropical climate. | Little or no insulation, weatherboard, fibro or brick veneer construction, large windows, no shading from the sun westerly facing aspect. |
Air Conditioner Capacity | Room Class | ||||
A | B | C | D | ||
Maximum Floor Area (m2) | |||||
1.7kW | Cooling | 17 | 14 | 12 | 10 |
Heating | 20 | 17 | 15 | 12 | |
2.0kW | Cooling | 20 | 16 | 14 | 12 |
Heating | 27 | 23 | 20 | 16 | |
2.5kW | Cooling | 25 | 21 | 18 | 15 |
Heating | 34 | 28 | 24 | 20 | |
3.5kW | Cooling | 35 | 29 | 25 | 21 |
Heating | 40 | 33 | 29 | 24 | |
5.0kW | Cooling | 51 | 43 | 36 | 30 |
Heating | 58 | 48 | 41 | 34 | |
6.0kW | Cooling | 60 | 50 | 45 | 37 |
Heating | 68 | 57 | 48 | 39 | |
7.1kW | Cooling | 71 | 59 | 51 | 42 |
Heating | 80 | 67 | 57 | 47 | |
8.0kW | Cooling | 80 | 67 | 57 | 47 |
Heating | 89 | 73 | 64 | 52 | |
9.5kW | Cooling | 95 | 78 | 68 | 57 |
Heating | 105 | 87 | 76 | 60 | |
10.0kW | Cooling | 100 | 83 | 73 | 62 |
Heating | 110 | 92 | 81 | 68 |
