Capacity | 6.0kW | |||
Model Name | Indoor Unit | S-6071PT3E | ||
Outdoor Unit | U-60PZ3R5 | |||
Cooling capacity : Heating capacity |
kW | 6.0 (2.0 – 7.1)
6.0 (1.8 – 7.0) |
||
BTU/h | 20,500 (6,800 – 24,200)
20,500 (6,100 – 23,900) |
|||
EER : COP W/W | 3.82 : 4.41 | |||
COP@H2 condition W/W | 3.19 | |||
Total power input Cooling : Heating kW | 1.57 : 1.36 | |||
TCSPF : HSPF |
Residential |
Hot Climate | 5.18 : 5.97 | |
Average Climate | 4.54 : 4.88 | |||
Cold Climate | 4.61 : 4.12 | |||
Commercial |
Hot Climate | 5.63 : 6.03 | ||
Average Climate | 5.63 : 5.40 | |||
Cold Climate | 5.98 : 4.66 | |||
Indoor Unit | ||||
Power source | Phase/Hz | 1 Phase / 50Hz | ||
V | 230V | 240V | |||
Dimension H x W x D Indoor mm | 235 X 1,275 X 690 | |||
Net weight Indoor kg | 34 | |||
Air volume (H/M/L) Cooling : Heating L/s | 334 / 283 / 242 : 334 / 283 / 242 | |||
Sound pressure level (H/M/L) Cooling : Heating dB(A) | 38 / 34 / 29 : 38 / 34 / 29 | |||
Sound power level (H/M/L) Cooling : Heating dB | 56 / 52 / 47 : 56 / 52 / 47 | |||
Number of fan speeds | 5 | |||
Drain piping mm | VP-20 | |||
Outdoor Unit | ||||
Power source | Phase/Hz | 1 Phase / 50Hz | ||
V | 230V | 240V | |||
Current (rated) Cooling : Heating A | 7.20 : 6.05 | 6.90 : 5.80 | |||
Dimension H × W × D mm | 695 x 875 x 320 | |||
Net weight kg | 43 | |||
Air volume Cooling : Heating L/s | 701 : 701 | |||
Sound pressure level (Silent mode) Cooling : Heating dB(A) | 48 (46) : 49 (47) | |||
Sound power level (Silent mode) Cooling : Heating dB | 66 (64) : 67 (65) | |||
Piping connections Liquid / Gas mm | Ø6.35 / Ø12.7*1 | |||
Pipe length range min. – max. m | 3 – 40 | |||
Elevation difference (OU located lower, OU located higher) m | 15, 30 | |||
Maximum chargeless length m | 30 | |||
Refrigerant at shipping / Additional gas amount g | R32 1,130 / 15 (g/m) | |||
Operating range Cooling : Heating ˚C | -10 to 46 : -15 to 24 |
Panasonic 6.0kW S-6071PT3E / U-60PZ3R5 Under Ceiling System Single Phase | Compact
Panasonic 6.0kW S-6071PT3E / U-60PZ3R5 Under Ceiling System Single Phase | Compact | NanoeX
CZ-RTC5B WIRED CONTROLLER INCLUDED
Description
6.0 kW Cooling
6.0 kW Heating
R32 Compact | NanoeX
