Toshiba Haori Designer RAS-B16E2KVRG-A / RAS-16E2AVRG-A 4.6kW Hi-Wall System Air Conditioner
Cooling Capacity: 4.6 kW
Heating Capacity: 5.5 kW
Elegant Design | Built-in Wi-Fi | Fabrics Options
| Indoor | RAS-B16E2KVRG-A | ||
| Outdoor | RAS-16E2AVRG-A | ||
| Cooling Capacity – Rated | co | kW | 4.6 |
| Cooling Capacity – Range | co | kW | 1.20 – 5.30 |
| Power input [rated (min – max)] | co | kW | 1.35 (0.29 – 1.72) |
| Operating current [rated (min – max)] | CO | A | 6.72 (1.75 – 8.30) |
| EER [rated (min – max)] | co | 3.41 (4.14 – 3.08) | |
| Heating Capacity – Rated | RC | kW | 5.5 |
| Heating Capacity – Range | RC | kW | 1.10 – 6.30 |
| Power input [rated (min – max)] | RC | kW | 1.52 (0.24 – 1.90) |
| Operating current [rated (min – max)] | RC | A | 7.35 ( 1.36 – 9.21) |
| COP [rated (min – max)] | RC | 3.62 (4.58 – 3.32) | |
| Indoor Unit | |||
| Airflow Volume (High/Mid/Low) | CO | l/s | 192 / 139 / 94 |
| Mositure removal | l/hr | 2.5 | |
| Dimension (WxLxH) | mm | 300x987x210 | |
| Net Weight | kg | 12 | |
| Sound Power at Cooling Operation (high) | co | dB | 58 |
| Indoor Fan Motor Output | w | 30 | |
| Outdoor Unit | |||
| Dimension (WxLxH) | mm | 550x780x290 | |
| Net Weight | kg | 33 | |
| Cooling Operating range (Inside/Outside) | co | oc | 21-32 / 10-46 |
| Heating Operating range | RC | oc | 0-28 / 15-24 |
| Sound Power at Cooling Operation (high) | co | dB | 62 |
| Outdoor Fan Motor Output | w | 43 | |
| Pipe Size | |||
| Liquid Side | (mm) | 6.35 | |
| Gas Side | (mm) | 9.52 | |
| Maximum Piping Length | (m) | 20 | |
| Maximum Piping Height difference | (m) | 12 | |
| Pre-Charge Length | (m) | 15 | |
| Compressor type | Single rotary type | ||
| Power Supply | V/ph/Hz | 220-240 / 1 / 50 | |
Key Features
- Elegant Design
- Ultra Pure Filter
- ON / OFF Timer
- Quiet Operation
- Fabrics options available
- Plasma Ionizer
- Built-in Wi-Fi
- Energy Monitoring
Design and reliability
Innovation, efficiency, high reliability, energy savings – these powerful values are at the heart of everything we do at Toshiba. For over 50 years, Toshiba has been providing its clients with the precision and expertise of Japanese quality.
Toshiba’s innovative inverter technology
Toshiba’s innovative rotary compressor technology
combines exemplary performance with outstanding
reliability. Minimising fluctuations to ensure a constant
temperature, it increases efficiency while significantly
reducing the risk of incidental noise.
Toshiba’s Inverter Technology allows the Haori to
regulate heating and cooling capacity at all times
by adjusting the compressor speed.
Ultra-Pure Filter
PM2.5 purification
• PM2.5 refers to particulate
matter coming from atmospheric pollution, that have a diameter of less than 2.5 micrometers
• Toshiba Ultra-Pure filter captures up to 94% of PM2.5, creating healthy living spaces at home (1)
• Prevents formation of mould and fungi
(1) Nantong deli purification equipment factory Co, Ltd
Toshiba’s Twin-Rotary Compressor
High efficiency
This compressor enables the adoption of a high-pressure refrigerant. High efficiency is evident in low speed operation ranges.
It can reduce energy consumption when operated in long stable conditions. Rotating with two rollers at the same time makes accurate
compressor rotation possible with less energy loss.
As a result, it offers a great reduction in energy consumption with powerful operation.
SMART AIR CONDITIONER
Enhance your comfort at home or away
- Energy Monitoring
- Smart speaker voice control functions compatible with Google Home Assistant & Amazon Alexa
Solution Well-Being
This intuitive remote control functions include:
Power select and ECO modes to reduce energy bills
Hi-power for rapid cooling or heating.
Toshiba HAORI remote control features a magnetic wall mounted holder.
High aesthetics and top Japanese technology combined. The new HAORI Inverter hi wall split has a fabric lining in a variety of colours, to match perfectly with the other decorative elements of your space.
Description
Cooling Capacity: 4.6 kW
Heating Capacity: 5.5 kW
Elegant Design | Built-in Wi-Fi | Fabrics Options
