TCL TCD71D1HWH-DV 7.2kW Reverse Cycle Split Ducted Air Conditioner
Air Conditioning Free Pickup Locations
TCL TCD71D1HWH-DV 7.2kW Reverse Cycle Split Ducted Air Conditioner

TCL TCD125D1HWH-DV 12.5kW Reverse Cycle Split High Static Ducted Air Conditioner

SKU: TCD125D1HWH-DV ( Indoor and Outdoor )

12.5kW Cooling |  15.0kW Heating
TCL TCD125D1HWH-DV 12.5kW Reverse Cycle Split High Static Ducted Air Conditioner
Wired Controller | 200PA High Static Pressure | Built-in Condensate Pump | 48°C Self-cleaning
5 Year Manufacturer’s Warranty


$3,180.00

Or own it from $122.31 weekly for 6 months* zip money
Or pay in slices, no interest ever
> >
Capacity R32 12.5KW
Model TCD125D1HWH-DV
Indoor Unit TCD125D1HWH-DV
Outdoor Unit TCD125D1HWH-DV
Type Heat pump
Control type Wired controller standard with 15m cable
Power supply
 Indoor Unit 1 phase, 220-240 V, 50 Hz
Outdoor Unit 1 phase, 220-240 V, 50 Hz
Rated Capacity
 Cool(kw) 12.5
Heat(kw) 15
Capacity Range
 Cool(kw) 4.0~13.5
Heat(kw) 4.3~15.8
Power input (Rated)
 Cool(kw) 3.77
Heat(kw) 3.75
EER Cool(kw/kw) 3.31
COP Heat(kw/kw) 4
AEER 3.28
ACOP 3.96
TCSPF(Residential) Hot/Average/Cold 4.71/4.37/4.56
HSPF(Residential) Hot/Average/Cold 4.63/4.10/3.52
Indoor unit
Dimensions H × W × D mm 380×1510×945
Packing dimensions H × W × D mm 455×1620×1010
Supply air opening flange H × W mm 245×1152
Return air opening H × W mm 2×400(Oval)
Indoor net weight
 kg 66
Gross weight kg 77
Airflow Rate(H/M/L)
 L/S 785/650/460
Sound pressure level@1.5m dB(A) 47
External Static Pressure(Rated ) Pa 50
External Static Pressure(Range ) Pa 0-200
Outdoor Unit
Dimensions H × W × D mm 1010×858×436
Packing dimensions H × W × D mm 1135x970x530
Outdoor net weight
 kg 73
Gross weight kg 85
Compressor Type Rotary
Sound pressure level
 Cooling / Heating dB(A) 57/58
Night quiet mode dB(A) 54
Sound power level
 dB(A) 70
Piping connection
 Liquid mm ø9.52/3/8”
Gas mm ø15.88/5/8”
Refrigerant control
 EEV
Ref. piping
 Max length m 50
Max height difference m 30
Refrigerant
 Type R32
Pre-charge pipe length m 20
Extra charge g/m 30
Cooling temperature °C 16-50
Heating temperature °C -15~24
Power supply side Outdoor unit



  •  Energy savings up to 75% compared to traditional systems
  •  Eco-friendly R290 refrigerant & DRED capable
  •  Wi-Fi control via the TCL Home App
  • AI and Holiday Modes for smarter energy use
  • Rapid heating from -7°C to 45°C ambient range
  • STC-2025 compliant
  • Built for long-term durability with anti-corrosion magnesium rod and enamel tank

TCL TCD125D1HWH-DV 12.5kW Reverse Cycle Split High Static Ducted Air Conditioner – Brochure

TCL TCD71D1HWH-DV 7.2kW Reverse Cycle Split Ducted Air Conditioner
$3,180.00

TCL TCD125D1HWH-DV 12.5kW Reverse Cycle Split High Static Ducted Air Conditioner
INSULATED PAIRED COPPER PIPE 9.5 x 15.88mm (3/8 x 5/8) 20 Meters length
$429.00

INSULATED PAIRED COPPER PIPE 9.5mm x 15.88mm (3/8 x 5/8) 20 Meters length – Shipping Included
$3,609.00 Bundle Price for Selected items

Description

12.5kW Cooling
15.0kW Heating

Eco Friendly | WIFI Smart Control
