Rinnai HINRP20M 2.0kW Multi Head System Indoor Unit Only | new model
Rinnai HINRP20M 2.0kW Multi Head System Indoor Unit Only
2.0 kW Cooling
2.3 kW Heating
Includes Wireless Remote Control | inbuilt WIFI
| Multi Indoor Unit – Wall Mounted | HINRP20M | ||
| Power Supply | V-Ph-Hz | 220~240 -1-50 | |
|
Cooling |
Rated Capacity | kW | 2.0 |
| Rated Input Power | W | 20 | |
| Rated Input Current | A | 0.10 | |
|
Heating |
Rated Capacity | kW | 2.3 |
| Rated Input Power | W | 20 | |
| Rated Input Current | A | 0.11 | |
| Airflow (Hi / Med / Lo) | L/s | 131 / 100 / 70 | |
| Sound Pressure (Hi / Med / Lo) @1.4m | dB(A) | 40 / 35 / 28 | |
|
Dimensions |
Net (W x D x H) |
mm |
717 x 193 x 302 |
| Gross (W x D x H) | 785 x 285 x 375 | ||
| Net / Gross Weight | kg | 7.0 / 9.3 | |
| Refrigeration Pipe Size: Liquid / Gas | mm | Φ6.35 / Φ9.52 | |
| Controller | Type | Wireless Remote Control | |
|
Operating Range |
Cooling |
oC |
17 ~ 32 |
| Heating | 0 ~ 30 | ||
To view the Brochure Click here
Description
2.0 kW Cooling
2.3 kW Heating
Includes Wireless Remote Control | inbuilt WIFI
R32
