Daikin CDXM25RVMA 2.5kW Cooling Only Bulkhead Multi Indoor Unit Only

SKU: CDXM25RVMA Cooling Only

2.5 kW Cooling

Daikin CDXM25RVMA 2.5kW Cooling Only Bulkhead Multi Indoor Unit Only

Controller BRC086A12




> > > Compare


Model name

CDXM25RVMA
Power supply 1 phase, 220-240 V, 50 Hz / 1 phase, 220-230 V, 60 Hz
Indoor air ow rate H l/s (cfm) 158 (335)
Indoor sound pressure level*1 H/L/SL dB(A) 35/31/29
Indoor sound power level H dB(A) 49
Fan speed 5 steps, quiet and automatic
Temperature control Microcomputer control
Dimensions H x W x D mm 200 x 900 x 620
Machine weight kg 25
Piping connections Liquid ( are)

mm

ø6.4
Gas ( are) ø9.5
Drain VP 20 (Inside diameter ø20, Outside diameter ø26)
Heat insulation Both liquid and gas pipes
External static pressure 40

Concealed Installation

The duct-connected type can be hidden inside the ceiling to create a clean exterior. It is suitable for living rooms with shallow tray ceilings or areas requiring a discreet appearance. Low and middle range external static pressure models are suitable for both uses, providing excellent design flexibility.

Daikin-Reverse-Cycle-Bulkhead-Multi-Indoor-Concealed-Installation

Compact Installation Height

Low external static pressure models are 200 mm high and require a space of just 240 mm between the drop ceiling and ceiling slab. With these compact measurements, any unit can easily be installed in even shallow tray ceilings.

Daikin-Reverse-Cycle-Bulkhead-Multi-Indoor-Compact-Installation-Height

Auto Fan Speed

Daikin inverter air conditioners automatically operate at low capacity most of the time. Turning your system on and off means it has to operate at higher capacity to cool and warm the room. To save electricity, it is more efficient to continue operation using Auto Fan Speed.
Selecting this function ensures your system operates with maximum efficiency and comfort without any further setting. After adjusting the fan speed to high to rapidly reach the set temperature, it switches to low. It then precisely maintains the room temperature using its inverter.
Daikin-Reverse-Cycle-Bulkhead-Multi-Indoor-Auto-Fan-SpeedDaikin-Reverse-Cycle-Bulkhead-Multi-Indoor-Auto-Fan-Speed-1

Click here to view the Brochure of Daikin CDXM25RVMA 2.5kW Cooling Only Bulkhead Multi Indoor Unit Only

Daikin Reverse Cycle Bulkhead Multi Indoor Unit Only

As a global air conditioning leader, Daikin is continually researching and identifying new and innovative ways to improve the performance of our products while simultaneously reducing their environmental impact. Our Super Multi NX multi-split system utilises R-32 refrigerant, which provides higher energy efficiency and lower global warming impact than R410A-based air conditioning.

The Super Multi NX outdoor unit is also capable of efficiently sharing capacity between several indoor units. Each indoor unit can be individually controlled to suit your specific requirements. This means airflow, temperature settings and scheduling can all be adjusted to meet personal preferences, delivering whole house comfort for everyone.

Description

2.5 kW Cooling

Cooling Only | Power-Airflow Dual Flaps
