Indoor | RAS-07E2KVG-A | |||
Outdoor | RAS-07E2AVG-A | |||
Cooling Capacity – Rated | CO | kW | 2 | |
Cooling Capacity – Range | CO | kW | 0.80 – 2.70 | |
Power input [rated (min – max)] | CO | kW | 0.53 (0.22-0.82) | |
Operating current [rated (min – max)] | CO | A | 2.7 (1.19 – 3.95) | |
AEER | CO | 3.74 | ||
Heating Capacity – Rated | RC | kW | 2.5 | |
Heating Capacity – Range | RC | kW | 0.90 – 3.30 | |
Power input [rated (min – max)] | RC | kW | 0.64 (0.20 – 1.15) | |
Operating current [rated (min – max)] | RC | A | 3.25 (1.07 – 5.50) | |
ACOP | RC | 3.91 | ||
Indoor Unit | ||||
Airflow Volume (High/Mid/Low) | CO | m³/hr | 520/370/230 | |
Mositure removal | l/hr | 0.8 | ||
Dimension (WxLxH) | mm | 293 x 798 x 230 | ||
Net Weight | kg | 9 | ||
Sound Power at Cooling Operation (high) | CO | dB | 57 | |
Outdoor Unit | ||||
imension (WxLxH) | mm | 240 x 660 x 530 | ||
Net Weight | kg | 22 | ||
Cooling Operating range (Outside) | CO | ◦C | -10 ~ 46 | |
Heating Operating range | RC | ◦C | -15 ~ 24 | |
Sound Power at Cooling Operation (high) | CO | dB | 63 | |
Pipe Size | ||||
Liquid Side | (mm) | 6.35 | ||
Gas Side | (mm) | 9.52 | ||
Maximum Piping Length | (m) | 15 | ||
Maximum Piping Height difference | (m) | 12 | ||
Chargeless Length | (m) | 15 | ||
Compressor type | Twin Rotary | |||
Power Supply | V/ph/Hz | 220-240V/1Ph/50Hz |
Toshiba Seiya Classic E2KVG07 2.0kW Reverse Cycle Inverter Split System Air Conditioner | R32
2.0 kW Cooling | 2.5 kW Heating
Toshiba Seiya Classic E2KVG07 2.0kW Reverse Cycle Inverter Split System Air Conditioner
Indoor unit: RAS-07E2KVG-A | Outdoor unit: RAS-07E2AVG-A
With Wireless Remote | System E2KVG07
R32 | Healthy Fresh Air
7 years manufacturer’s warranty
- Frost Protection Mode
- Boost Mode
- WiFi Optional
- 3D Airflow [6.0kW ~ 10.0kW models]
- Eco Mode
- Magic Coil
- Outdoor Noise Reduction
- Weekly Timer
- Comfort Sleep Mode
- Wireless Controller Included
Description
2.0 kW Cooling
2.5 kw Heating
R32 | Healthy Fresh Air
