Temperzone CWP178 17.8kW Water Cooled Inverter Package | Vertical | 3 Phase

SKU: CWP178

The sky’s the limit with Temperzone water-cooled systems

Rather than having to plan your entire air conditioning layout in advance, Temperzone’s water-cooled modular technology offers you the unique ability to expand or adapt your system as a building’s commercial demands evolve.

The CWP-K Series of vertical discharge water cooled package units have been designed to provide year round comfort to the space they are serving.




Model                                       CWP 178
 Capacity (Range) kW

Nominal Cooling Capacity 2 (kW) 17.8
Net Cooling Capacity (kW) 17.25
Efficiency Cooling (EER/AEER) 7 3.58 / 3.52
Heating Capacity 3 (kW) 16.41
Efficiency Heating (COP/ACOP) 3.98 / 3.97
Electric Heat Option (kW) 6.5

Nominal Supply Air Flow



l/sec 920

Sound Pressure Level 4



dB(a) 62.9
Power Supply 1 3 Phase (400V 50Hz)
Run Amps at Nominal Conditions 6

8.2 / 8.0 / 8.0

Heat Exchanger

Water Flow



l/sec 1.08

Water Pressure Drop



kPa / psi 34.5 / 5

Water Connections



ø mm / BSP 32 / ¾”

Dimensions (mm)



Width 855
Height 1400
Depth 780

Weight (kg)



Weight (excluding water) 226



  • EC fans CWP 63~178
  • Plug fans CWP 217~568
  • Variable pitch pulley CWP 890 & 1030
  • Wide ESP
  • Top discharge supply air
  • Simple access
  • Advanced powder coating

Temperzone CWP178 17.8kW Water Cooled Inverter Package | Vertical | 3 Phase – Brochure

Description

17.8kW Cooling
HIGH-EFFICIENCY EC FAN
