Temperzone CWP132 13.2kW Water Cooled Inverter Package | Vertical | Single Phase

SKU: CWP132

Temperzone CWP132 13.2kW Water Cooled Inverter Package | Vertical | Single Phase



Model                                               CWP 132
Capacity (Range) kW

Nominal Cooling Capacity 2 (kW) 13.14
Net Cooling Capacity (kW) 12.77
Efficiency Cooling (EER/AEER) 7 3.52 / 3.51
Heating Capacity 3 (kW) 11.9
Efficiency Heating (COP/ACOP) 3.86 / 3.80
Electric Heat Option (kW) 5.5

Nominal Supply Air Flow



l/sec 770

Sound Pressure Level 4



dB(a) 58.6
Power Supply 1 Single Phase (230 – 240V 50Hz)
Run Amps at Nominal Conditions 6

16.0

Heat Exchanger

Water Flow



l/sec 0.8

Water Pressure Drop



kPa / psi 41.4 / 6

Water Connections



ø mm / BSP 32 / 1¼”

Dimensions (mm)



Width 855
Height 1400
Depth 780

Weight (kg)



Weight (excluding water) 216



Compact & efficient yet powerful

Temperzone has made things simple by creating a compact unit that’s big on innovation. So compact it makes perfect sense as an energy efficient solution for new or replacement projects. With the use of an inverter compressor combined with an electronic expansion valve the CWP 90 ECONEX provides a precise load variation response and superior part load performance for closer comfort control and higher energy efficiency.

HIGH EFFICIENCY EC FAN

EC fans CWP 63~178.

EC technology motors provide higher efficiency and energy savings compared with AC motors.
EC stands for Electronically Commutated often referred to as a Brushless DC electric motor (BLDC motor) with integrated controller electronics. The fan is able to be speed controlled by 0-10VDC or as a fixed amount of speeds selectable on the unit.

PLUG FANS

CWP 217~568.

VARIABLE PITCH PULLEY

CWP 890 & 1030.

WIDE ESP

Models with EC or Plug fans make airflow control simple.

EXTERNAL CONTROL

External controller can easily be connected through relay terminals

POWDER COATED CABINET

Advanced powder coating ensures sheet metal life and provide a more aesthetically pleasing finish.

TOP DISCHARGE SUPPLY AIR

All models have a standard top supply air configuration however some larger models have an option for back supply air.

COOLING WITH ELECTRIC HEATING

CWP 60 ~ 178 models are available as cooling only with electric heaters. Heaters have double high-temperature safeties.

KNOCK DOWN

Units are available in knock down form for difficult to access plant rooms.

SERVICE ACCESS

Simple access to compressors and heat exchangers.

Click here to view the brochure of Temperzone Water Cooled Inverter Package | Vertical

Description

13.2 kW Cooling
