TECO TWW53HVAG 5.3kW Inverter Window Wall Reverse Cycle Air Conditioner

SKU: TWW53HVAG

5.3 kW Cooling | 4.8 kW Heating
TECO TWW53HVAG 5.3kW Inverter Window Wall Reverse Cycle Air Conditioner
High Density Filters, Filter Dirty Alarm, Gold Fin Protection, Filter Dirty Alarm, Electronic Control with Remote

H428mm x W660mm x D800mm | 5 Year Domestic Warranty


$1,445.00

Or own it from $55.58 weekly for 6 months* zip money
Or pay in slices, no interest ever
> > >
TECO INVERTER WINDOW WALL AIR CONDITIONER — 5.3kW
TECO Model — TWW53HVAG
TECO EAN Code — 9346998006756
Power Supply
 Rated Voltage V 220-240
Rated Frequency Hz 50
Phases — 1
Cooling Capacity W 5300
Cooling Capacity Range W 5300(Rated)/2600(Mid)
Cooling Power Input W 1600
Cooling Power Input Range W 1600(Rated)/700(Mid)
Cooling Power Current A 7
Cooling Power Current Range A 7.0(Rated)/3.4(Mid)
Heating Capacity W 4800
Heating Capacity Range W 4800(Rated)/2450(Mid)
Heating Power Input W 1400
Heating Power Input Range W 1400(Rated)/600(Mid)
Heating Power Current A 6.6
Heating Power Current Range A 6.6(Rated)/3.0(Mid)
EER W/W 3.3125
AEER W/W 3.2827
Cooling Star Rating (Hot / Mixed / Cold) 2.5/2.5/2.5
Cooling Energy Consumption (Hot / Mixed / Cold) kWh/year 1624/544/356
COP W 3.4286
ACOP W 3.3934
Heating Star Rating (Hot / Mixed / Cold) 2/1.5/1.5
Heating Energy Consumption (Hot / Mixed / Cold) kWh/year 118/760/2001
Noise (Energy Label – Indoor / Outdoor) dB(A) 65/69
Rated Input (Max) W 2400
Rated Current (Max) A 10
Inactive Energy (Avg) W 4.3
Air Flow Volume(H/M/L) m3/h 800/700/620
Air Flow Volume(H/M/L) L/s 222/194/172
Air Flow Volume(H/M/L) CFM 471/412/365
Dehumidifying Volume L/h 2.2
Dehumidifying Volume Pint/h 4.65
Application Area m2 23-34
Permissible Excessive Operating Pressure for the Discharge Side MPa 4.3
Permissible Excessive Operating Pressure for the Suction Side MPa 2.5
Maximum Allowable Pressure MPa 4.3
Climate Type — T1
Isolation — I
Moisture Protection — IPX4<outdoor>
Evaporater Coil Hydrophilic Coating — Blue
Condensor Coil Hydrophilic Coating — Gold
Dimension (W×H×D) mm 660x428x800
Recommended Cut Out Size (W×H) mm 665×433
Dimension of Carton Box (L×W×H) mm 887x736x490
Dimension of Package (L×W×H) mm 890x739x505
Net Weight kg 56
Gross Weight kg 60
Stacking layers 6
Refrigerant — R32
Refrigerant Charge kg 0.9
Indoor Side
 Fan Type Centrifugal
Set Temperature Range ℃ 16～30
Sound Pressure Level (H/M/L) dB (A) 54/52/50
Sound Power Level (H/M/L) dB (A) 64/62/60
Outdoor Side
Cooling Operation Ambient Temperature Range ℃ 18～43
Heating Operation Ambient Temperature Range ℃ -7～24
Sound Pressure Level (H/M/L) dB (A) 61/59/57
Sound Power Level (H/M/L) dB (A) 71/69/67
Container Loading Quantity (20GP/40GP/40HQ) 72/156/195
Electronic Control with Remote Controller YES
General Function
 Auto YES
Cooling YES
Heating YES
Dehumidify YES
Sleep YES
Timer YES
Auto Swing (Horizontal Auto Swing) YES
Air Flow YES
Memory YES
Auto Fan YES
Filter Dirty Alarm YES
Soft Start YES
Low Voltage Startup YES
Intelligent Preheating YES
Auto Restart YES
Self Diagnosis YES
Silver Ion Sterilizing Filter YES



  • Powerful and versatile, the TECO 5.3kW Inverter Window/Wall Air Conditioner is tailored for large spaces. With advanced features like the latest Inverter Technology, Intelligent Preheating and Auto Swing, it provides superior climate control and evenly distributed airflow. Its robust 5.3kW capacity ensures comfort even in extreme temperatures, making it perfect for spacious living areas or offices.

Description

5.3 kW Cooling
4.8 kW Heating
Inverter Type
