Samsung AM040NXMDER/EU 12.1kW DVM S Mini Double Fan Outdoor 1 Phase
Samsung AM040NXMDER/EU 12.1kW DVM S Mini Double Fan Outdoor 1 Phase
12.1 kW Cooling | 12.1 kW Heating
Heat Recovery | Heat Pump
- Specification
- Features
- Brochure
- Description
- Faqs
- Additional information
- Reviews
| Model | AM040NXMDER/EU | |||
| Power Supply | Ø, V, Hz | 1, 220-240, 50 | ||
|
Capacity (Nominal)
|
Rating | HP | 4 | |
| Cooling1 | kW | 12.1 | ||
| Heating2 | kW | 12.1 | ||
| Maximum Number of Connectable Indoor Units | 8 | |||
|
Connectable Total Indoor Capacity
|
Minimum | kW | 6 | |
| Maximum | kW | 15.7 | ||
|
Current
|
MCA4 | A | 22 | |
| MFA4 | A | 25 | ||
|
Energy Efficiency Ratio
|
Cooling1 | W/W | 4.5 | |
| Heating2 | W/W | 4.8 | ||
|
Compressor
|
Type | Twin BLDC Rotary | ||
| Oil Type | PVE | |||
|
Fan
|
Type | Propeller | ||
| Quantity | 2 | |||
| ̈θѤͱи ŵɇϩʪ | l/s | 1667 | ||
| External Static Pressure | Pa | 29 | ||
|
Piping Connections
|
Liquid Pipe | mm/inch | 9.52, 3/8″ | |
| Gas Pipe | mm/inch | 15.88, 5/8″ | ||
| High Pressure Gas Pipe, for Heat Recovery | mm/inch | 15.88, 5/8″ | ||
|
Allowable Piping Length
|
Piping Length, Outdoor to Indoor. Maximum (Equivalent) | m | 150 (175) | |
|
Piping Height.
Outdoor Above (Outdoor Below) |
m |
50 (40)
|
||
|
Unit Weight
|
kg | 97 | ||
|
External Dimension
|
W x H x D
|
mm | 940 x 1,210 x 330 | |
|
Factory Charge
|
R410A
|
kg | 3.2 | |
|
Sound3
|
Sound Pressure – Cooling
|
dB(A) | 50 | |
|
Sound Pressure – Heating
|
dB(A) | 52 | ||
|
Sound Power
|
dB(A) | 67 | ||
|
Operating Ambient Temperature Range
|
Cooling
|
°C | -5 to 48°C | |
| Heating | °C | -25 to 26°C | ||
Universal outdoor unit, can be used as a heat pump outdoor or as a heat recovery outdoor. For heat recovery operation, there are no conflict in operation mode requirement, providing simultaneous Heating and Cooling operation when use in conjunction with HR changer and Mode Control Unit (MCU). Connectable indoor units means you can air condition spaces and with
precision control to meet your comfort. You can position the outdoor unit away from the indoor unit, so as not to
interfere with your main living space.
Description
12.1 kW Cooling
12.1 kW Heating
Heat Recovery | Heat Pump
Q1: What are the main features of the Samsung DVM S Mini Double Fan Outdoor 1 Phase?
The Samsung DVM S Mini Double Fan Outdoor 1 Phase is a compact outdoor unit designed for multi-room air conditioning applications. It features a dual-fan outdoor design, inverter technology, reliable heating and cooling performance, and flexible connection options for multiple indoor units.
Q2: Is the Samsung DVM S Mini Double Fan Outdoor 1 Phase energy efficient?
Yes. The Samsung DVM S Mini Double Fan Outdoor 1 Phase uses inverter technology to vary compressor operation according to the required heating or cooling load. This helps maintain consistent indoor temperatures while supporting efficient energy use across different operating conditions.
Q3: How many indoor units can be connected to the Samsung DVM S Mini Double Fan Outdoor 1 Phase?
The Samsung DVM S Mini Double Fan Outdoor 1 Phase is designed to operate with multiple indoor units from a single outdoor unit. The maximum number of connectable indoor units depends on the specific outdoor model and system configuration, providing flexibility for multi-room applications.
Q4: Is the Samsung DVM S Mini Double Fan Outdoor 1 Phase suitable for larger multi-room applications?
Yes. The Samsung DVM S Mini Double Fan Outdoor 1 Phase is suitable for applications requiring air conditioning across multiple rooms or zones. Its multi-split configuration can help reduce the need for separate outdoor units while providing individual indoor comfort control.
Q5: Not sure what size air conditioner you need?
Use our free Air Conditioning Calculator & Size Guide as a starting point to estimate the right capacity for your room or home. Please note this calculator is a guide only — actual requirements may vary depending on your ceiling height, insulation, window size, orientation, and local climate conditions.
For a more accurate sizing recommendation tailored to your specific home or office, we recommend booking a quote with our team. Our air conditioning experts will assess your space and help you choose the perfect Samsung DVM S Mini Double Fan Outdoor 1 Phase unit with confidence — ensuring maximum comfort, efficiency, and value for money.
For more information about the Samsung DVM S Mini Double Fan Outdoor 1 Phase and available models, click here.
Additional information
| Weight | 110 kg |
|---|
