Mitsubishi Heavy Industries Ciara DXK21ZTLA-WF-Set 6.3kW Inverter Split System Air Conditioner

SKU: DXK21ZTLA-WF-Set | DXK21ZTLA-WF | DXC21ZTLA-W

6.3kW Cooling | 8.0kW Heating
Mitsubishi Heavy Industries Ciara DXK21ZTLA-WF-Set 6.3kW Inverter Split System Air Conditioner
Indoor: DXK21ZTLA-WF | Outdoor : DXC21ZTLA-W | System: DXK21ZTLA-WF-Set

5 years manufacturer’s warranty
Includes Wireless Controller
Includes WIFI Built-in

$1,807.65

Or own it from $69.53 weekly for 6 months*

Or pay in slices, no interest ever

CAPACITY				6.3kW
Indoor				DXK21ZTLA-WF
Outdoor				DXC21ZTLA-W
Power Source (Outdoor Unit)				1 Phase, 220 – 240V, 50Hz
*Operation Data	Nominal Capacity (Range)	Cooling T1	kW	6.3 (1.2~7.1)
		Heating H1		7.1 (1.0~8.5)
		Heating H2		6.6
	Power Consumption	Cooling T1		1.84 (0.27-2.39)
		Heating H1		2.01 (0.25~2.89)
	Maximum Power Consumption			3.18
	Running Current	Cooling T1	A	7.7
		Heating H1		8.5
	Inrush Current, Maximum Current			5.0, 17
	EER	Cooling T1		3.42
	COP	Heating H1		3.53
	Sound Power Level (JIS C9612)	Outdoor	dB(A)	64
	Sound Pressure Level (JIS C9612)	Indoor		46-43-38-30
		Outdoor		52
Energy Label (GEMS 2019)		Hot	Cooling	-3
			Heating	-3
		Average	Cooling	-3
			Heating	-2.5
		Cold	Cooling	-3
			Heating	-2
External dimensions (HXWXD)		Indoor	mm	294x998x230
		Outdoor		640×800(+71)x290
Net weight		Indoor	kg	12
		Outdoor		42.5
Airflow		Cooling (Indoor)	l/s	283-245-202-157
		Heating (Indoor)		307-287-235-193
Installation Data	Refrigerant (Type, Amount, Pre-charge Length)	Quantity	kg	(R32) 1.20
		Pre-Charged to Pipe	m	15
	Refrigerant Piping	Liquid line	mm	Ø6.35
		Gas line		Ø12.7
	Connection Method			Flare connection
	Maximum Pipe Length (One Way)		m	30
	Max Vertical Height Diff. Between O.U. and I.U.			20 ( O.U. above I.U. ) / 20 ( O.U. below I.U. )
Standard accessories				Allergen Clear Filter x 1, Wi-Fi
Optional parts				Interface kit (SC-BIKN2-E) / Photocatalytic Washable Deodorizing Filter
Demand Response (AS4755)				Yes

BUILT-IN WI-FI
Wi-Fi & voice control compatibility now includ- ed as standard*. Control your air-conditioner anywhere, anytime with your smartphone.

BACKLIT REMOTE CONTROL
Easy to use remote with backlit screen for dark/night time operation. Accurate tempera- ture control via 0.5°C increments.

SILENT MODES
Two levels of silent mode are available to further reduce the outdoor unit noise level.

COMPACT DESIGN
A compact and lightweight design allows for improved installation flexibility and installation into smaller spaces such as apartments.

Mitsubishi Heavy Industries Ciara DXK21ZTLA-WF-Set 6.3kW Inverter Split System Air Conditioner – Brochure
