HITACHI PPIM-5.0UFA1NQ - PPAS-5.0UFASNQ1 12.5kW R32 airCore700 Underceiling split system - Single phase

HITACHI PPIM-6.0UFA1NQ / PPAS-6.0UFASNQ1 14.0kW R32 airCore700 Underceiling split system – Single phase

SKU: PPFC-6.0UFA1NQ / PAS-6.0UFASNQ1

14.0kW Cool – 16.0kw Heat / HITACHI PPFC-6.0UFA1NQ / PAS-6.0UFASNQ1 14.0kW R32 airCore700 Underceiling split system – Single phase

Indoor: PPFC-6.0UFA1NQ – 14.0kW R32 airCore700 Under-Ceiling Indoor Unit
Outdoor: PAS-6.0UFASNQ1 – 14.0kW R32 airCore700 1Ø Inverter Outdoor Unit – Heat Pump
ALL AIRCORE 700 UNDERCEILING SPLIT SYSTEMS INCLUDE: PC-ARFG2-Z WIRED CONTROLLER


$4,960.00

Or own it from $190.77 weekly for 6 months* zip money
Or pay in slices, no interest ever
> > >
IDU PPFC-6.0UFA1NQ
ODU PAS-6.0UFASNQ1
Power supply (Indoor) V/Ph/Hz 220~240V / 1Ø / 50Hz
Power supply (Outdoor) V/Ph/Hz 220~240V / 1Ø / 50Hz
Max. power input kW 6.27
Max. current input A 28.5
Cooling
 Rated Capacity kw 14
Capacity Range[Min~Max] kW 5.0~16.0
Heating
 Rated Capacity kW 16
Capacity Range[Min~Max] kW 5.5~18.0
Power comsumption
 Cooling kW 4.35
Heating kW 4.5
AEER Cooling 3.18
ACOP Heating 3.52
TCSPF(Cooling) Commercial /Residential
 Hot 4.98/4.61
Average 5.08/4.22
Cold 5.45/4.40
HSPF(Heating) Commercial /Residential
 Hot 4.43/4.42
Average 3.95/3.58
Cold 3.33/3.08
Indoor Unit
 Fan Motor Output W 181
Air Flow[Hi2/Hi1/Hi/Med/Lo/SLo] L/s 550/480/410/370
Sound Pressure Level
[Hi2/Hi1/Hi/Med/Lo/SLo] dB[A]		 52/49/45/41
Sound Power Level dB[A] 68
Dimension [W×H×D] mm 1580×230×680
Packing [W×H×D] mm 1690×340×830
Net/Gross Weight kg 48/55
Drainage water pipe diameter mm VP25
Outdoor Unit
 Compressor Type ATH356SKRC9EQ
Compressor R.L.A 11.5
Fan Motor F.L.A 0.62
Fan Motor Output W 138
Air Flow m3/h 8200
Sound Pressure Level-Cooling dB[A] 56
Sound Pressure Level-Heating dB[A 57
Sound Pressure Level-Night dB[A] 54
Sound Power Level dB[A] 73
Throttle Type Electronic Expansion Value
Dimension [W×H×D] mm 950×1380×320
Packing [W×H×D] mm 1070×1520×470
Net/Gross Weight kg 108.0/118.5
Refrigerant type /Quantity
 Type R32
Charge Kg 3.4
GWP 675
Design pressure H/L 4.15/2.21
Refrigerant pipe
 Liquid side/Gas side mm Φ9.52/Φ15.88
Max. pipe length m 75
Max. pipe length m 30
Add Refrigerant Amount g/m 35
Chargeless m 30
Guaranteed Temperature Operation Range
 Cooling °C -5~52
Heating °C -20~15.5

RAF-50NXA1

Key Features

  • 5.0kW Cooling Capacity
  • 6.0kW Heating Capacity
  • AEER (Cooling) 3.29
  • ACOP (Heating) 3.83
  • All DC Controlled – Including DC Controlled indoor unit
  • Power active module (PAM system) Ensures optimum efficiency
  • Twin Inverter rotary compressor for smoother quieter operation
  • Lower impact on the environment due to higher operating efficiencies and the use of a non-ozone depleting refrigerant, R410A
  • Auto restart – Memorises last settings prior to power failure and restarts at the same settings
  • Clean Air – Prefilter with 2 stage Nano titanium filtration*, Anti bacterial tangential fan, for cleaner air. *Nano Titanium Filtration is standard on RAS 50, 60, 70 and 80 models and optional on the RAS 25 and 35 models.
  • Multi directional airflow – For smoother air distribution
  • Low Start current – Minimizing power input
  • Anti corrosion coating – Improves coil durability
  • LCD Remote Control
  • 5 Year full domestic warranty
  • Star rating (Cool / Heat) 2.0 / 3.0

HITACHI PPFC-6.0UFA1NQ / PAS-6.0UFASNQ1 14.0kW R32 airCore700 Underceiling split system – Brochure

Description

14.0 kW Cooling
16.5 kW Heating
