F3 Type Mid Static Adaptive Ducted units are slim and boast excellent performance, making them ideal for installation environments with low ceilings and vertical installations. They also offer the next level of air quality thanks to the nanoe X Generator Mark3, effective even in large spaces.
| INDOOR UNITS – Adaptive Ducted – nanoe™X | |||
| Mid Static | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MF3E5AN | 2.2 | 2.5 | |
| S-28MF3E5AN | 2.8 | 3.2 | |
| S-36MF3E5AN | 3.6 | 4.2 | |
| S-45MF3E5AN | 4.5 | 5 | |
| S-56MF3E5AN | 5.6 | 6.3 | |
| S-60MF3E5AN | 6 | 7.1 | |
| S-73MF3E5AN | 7.3 | 8 | |
| S-90MF3E5AN | 9 | 10 | |
| S-112MF3E5AN | 10.6 | 11.4 | |
| S-140MF3E5AN | 14 | 16 | |
| S-160MF3E5AN | 16 | 18 | |
HHH
M1 Type Slim Low Static Ducted units have a slim design with a height of only 200 mm, making them ideal for small, compact spaces under the ceilings of buildings such as hotels.
| INDOOR UNITS – Slim Low Static Ducted | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MM1E5B | 2.2 | 2.5 | |
| S-28MM1E5B | 2.8 | 3.2 | |
| S-36MM1E5B | 3.6 | 4.2 | |
| S-45MM1E5B | 4.5 | 5 | |
| S-56MM1E5B | 5.6 | 6.3 | |
Z1 Type Slim Low Static Ducted Twenty Series units have a slim design with a height of only 200 mm, making them ideal for small, compact spaces under the ceilings of buildings such as hotels.
| INDOOR UNITS – Slim & Narrow Ducted | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MZ1H4A | 2.2 | 2.5 | |
| S-28MZ1H4A | 2.8 | 3.2 | |
| S-36MZ1H4A | 3.6 | 4.2 | |
| S-45MZ1H4A | 4.5 | 5 | |
| S-56MZ1H4A | 5.6 | 6.3 | |
| S-60MZ1H4A | 6 | 7.1 | |
| S-73MZ1H4A | 7.3 | 8 | |
Panasonic VRF/Mini VRF Air Conditioners E2 Type High Static Ducted/High Fresh Air Ducted units offer improved design flexibility in extended duct layouts thanks to their increased external static pressure. They also provide 100% fresh air intake for ventilation (except for S-180ME2E5).
| INDOOR UNITS – High Static Ducted | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-180ME2E5 | 18 | 20 | |
| S-224ME2E5 | 22.4 | 25 | |
| S-280ME2E5 | 28 | 31.5 | |
E1 Type High Static Ducted units are hidden in the ceiling to provide an ideal match for luxury residences and light commercial buildings, offering greater freedom of duct design.
| INDOOR UNITS – High Static Compact Ducted | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-90ME1R5A | 9 | 10 | |
| S-112ME1R5A | 11.2 | 12.5 | |
| S-140ME1R5A | 14 | 16 | |
| S-160ME1R5A | 16 | 18 | |
K2 Type Wall Mounted units boast a stylish design and are compact and lightweight, making them easy to install. Their quiet operation makes them ideal for small offices, hotel rooms, and hospital rooms.
| INDOOR UNITS – Wall Mounted | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MK2E5B | 2.2 | 2.5 | |
| S-28MK2E5B | 2.8 | 3.2 | |
| S-36MK2E5B | 3.6 | 4.2 | |
| S-45MK2E5B | 4.5 | 5 | |
| S-56MK2E5B | 5.6 | 6.3 | |
| S-73MK2E5B | 7.3 | 8 | |
| S-106MK2E5B | 10 | 11.4 | |
U2 Type 4-Way Cassette units have a flat design and a built-in drain pump that allows for flexible installation and design options that blend in with interiors and buildings. They also offer the next level of air quality thanks to the nanoe X Generator Mark3, effective even in large spaces
| VRF Indoor – 4-WAY Cassette – nanoe™X | ||||
| Model | Cool (kW) | Heat (kW) | Fascia |
|
| S-22MU2E5BN | 2.2 | 2.5 | CZ-KPU3H | |
| S-28MU2E5BN | 2.8 | 3.2 | CZ-KPU3H | |
| S-36MU2E5BN | 3.6 | 4.2 | CZ-KPU3H | |
| S-45MU2E5BN | 4.5 | 5 | CZ-KPU3H | |
| S-56MU2E5BN | 5.6 | 6.3 | CZ-KPU3H | |
| S-60MU2E5BN | 6 | 7.1 | CZ-KPU3H | |
| S-73MU2E5BN | 7.3 | 8 | CZ-KPU3H | |
| S-90MU2E5BN | 9 | 10 | CZ-KPU3H | |
| S-112MU2E5BN | 10.6 | 11.4 | CZ-KPU3H | |
| S-140MU2E5BN | 14 | 16 | CZ-KPU3H | |
| S-160MU2E5BN | 16 | 18 | CZ-KPU3H | |
Y3 Type 4-Way Mini Cassette units feature a design compact enough to fit into a 60 × 60 cm ceiling grid with easy installation. They also offer the next level of air quality thanks to the nanoe X Generator Mark3.
| VRF Indoor – 4-WAY Mini Cassette | ||||
| Model | Cool (kW) | Heat (kW) | Fascia |
|
| S-22MY3E | 2.2 | 2.5 | CZ-KPY4 | |
| S-28MY3E | 2.8 | 3.2 | CZ-KPY4 | |
| S-36MY3E | 3.6 | 4.2 | CZ-KPY4 | |
| S-45MY3E | 4.5 | 5 | CZ-KPY4 | |
| S-56MY3E | 5.6 | 6.3 | CZ-KPY4 | |
L1 Type 2-Way Cassette units are very thin, compact, and light, allowing for flexibility in installation. The fan has been redesigned to achieve its size and weight reductions.
| VRF Indoor – 2-WAY Cassette | ||||
| Model | Cool (kW) | Heat (kW) | Fascia |
|
| S-22ML1E5 | 2.2 | 2.5 | CZ-02KPL2 | |
| S-28ML1E5 | 2.8 | 3.2 | CZ-02KPL2 | |
| S-36ML1E5 | 3.6 | 4.2 | CZ-02KPL2 | |
| S-45ML1E5 | 4.5 | 5 | CZ-02KPL2 | |
| S-56ML1E5 | 5.6 | 6.3 | CZ-02KPL2 | |
| S-73ML1E5 | 7.3 | 8 | CZ-03KPL2 | |
D1 Type 1-Way Cassette units feature a slim design that can be installed in small ceiling spaces. The quiet yet powerful fan blows air to the floor from a ceiling height of up to 4.2 m.
| VRF Indoor – 1-WAY Cassette | ||||
| Model | Cool (kW) | Heat (kW) | Fascia |
|
| S-28MD1E5 | 2.2 | 2.5 | CZ-KPD2 | |
| S-36MD1E5 | 3.6 | 4.2 | CZ-KPD2 | |
| S-45MD1E5 | 4.5 | 5 | CZ-KPD2 | |
| S-56MD1E5 | 5.6 | 6.3 | CZ-KPD2 | |
| S-73MD1E5 | 7.3 | 8 | CZ-KPD2 | |
T2 Type Under Ceiling units offer excellent energy-saving performance and comfortable long-distance airflow distribution, making them ideal for stores and schools.
| VRF Indoor – Under Ceiling | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-36MT2E5A | 3.6 | 4.2 | |
| S-45MT2E5A | 4.5 | 5 | |
| S-56MT2E5A | 5.6 | 6.3 | |
| S-73MT2E5A | 7.3 | 8 | |
| S-106MT2E5A | 10.6 | 11.4 | |
| S-140MT2E5A | 14 | 16 | |
P1 Type Floor Standing units have a compact design and are an ideal solution for providing perimeter air conditioning. A standard wired controller can be integrated into the units.
| VRF Indoor – Floor Standing | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MP1E5 | 2.2 | 2.5 | |
| S-28MP1E5 | 2.8 | 3.2 | |
| S-36MP1E5 | 3.6 | 4.2 | |
| S-45MP1E5 | 4.5 | 5 | |
| S-56MP1E5 | 5.6 | 6.3 | |
| S-71MP1E5 | 7.1 | 8 | |
R1 Type Concealed Floor Standing units are only 229 mm deep and can be easily concealed in the perimeter area for powerful and effective air conditioning.
| VRF Indoor – Concealed Floor Standing | |||
| Model | Cool (kW) | Heat (kW) |
|
| S-22MR1E5 | 2.2 | 2.5 | |
| S-28MR1E5 | 2.8 | 3.2 | |
| S-36MR1E5 | 3.6 | 4.2 | |
| S-45MR1E5 | 4.5 | 5 | |
| S-56MR1E5 | 5.6 | 6.3 | |
| S-71MR1E5 | 7.1 | 8 | |
For small-scale commercial and residential use. The Mini-FSV system LE Series is designed for light commercial and residential use with extraordinary energy-saving performance and a high external static pressure of 35 Pa.
| MINI FSV | |||
| Single Phase |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-4LE2R5 | 12.1 | 12.5 | |
| U-5LE2R5 | 14 | 16 | |
| U-6LE2R5 | 15.5 | 16.5 | |
| MINI FSV | |||
|
Single Phase – Anti Corrosion
|
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-4LE2R5E | 12.1 | 12.5 | |
| U-5LE2R5E | 14 | 16 | |
| U-6LE2R5E | 15.5 | 16.5 | |
| MINI FSV | |||
| Three Phase |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-4LE2R8 | 12.1 | 12.5 | |
| U-5LE2R8 | 14 | 16 | |
| U-6LE2R8 | 15.5 | 16.5 | |
| U-8LE1R8 | 22.4 | 25 | |
| U-10LE1R8 | 25 | 28 | |
| MINI FSV | |||
| Three Phase – Anti Corrosion |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-8LE1R8E | 22.4 | 25 | |
| U-10LE1R8E | 25 | 28 | |
Extraordinary energy-saving performance and powerful operation The FSV system ME2 Series is designed for outstanding energy-saving performance, powerful operation, high reliability, and comfort surpassing anything that was previously possible.
| 2-PIPE FSV-EX | |||
| Three Phase |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-8ME2R8 | 22.4 | 25 | |
| U-10ME2R8 | 28 | 31.5 | |
| U-12ME2R8 | 33.5 | 37.5 | |
| U-14ME2R8 | 40 | 45 | |
| U-16ME2R8 | 45 | 50 | |
| U-18ME2R8 | 50 | 56 | |
| U-20ME2R8 | 56 | 63 | |
| 2-PIPE FSV-EX | |||
| Three Phase – Anti Corrosion |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-8ME2R8E | 22.4 | 25 | |
| U-10ME2R8E | 28 | 31.5 | |
| U-12ME2R8E | 33.5 | 37.5 | |
| U-14ME2R8E | 40 | 45 | |
| U-16ME2R8E | 45 | 50 | |
| U-18ME2R8E | 50 | 56 | |
| U-20ME2R8E | 56 | 63 | |
For simultaneous heating and cooling The simultaneous heating and cooling FSV system MF3 Series is designed to represent the ultimate solution for the most discerning customers and demanding installation environments.
| 3-PIPE FSV-EX | |||
| Three Phase |
|
||
| Model | Cool (kW) | Heat (kW) | |
| U-8MF3R7 | 22.4 | 25 | |
| U-10MF3R7 | 28 | 31.5 | |
| U-12MF3R7 | 33.5 | 37.5 | |
| U-14MF3R7 | 40 | 45 | |
| U-16MF3R7 | 45 | 50 | |
| Model | Description | Series Compatibility |
| CZ-KPY4 | 4-WAY Mini Cassette Fascia | 4-WAY Mini Cassette |
| CZ-KPD2 | 1-WAY Cassette Fascia | 1-WAY Cassette |
| CZ-02KPL2 | 2-WAY Cassette Fascia (22 – 56) | 2-WAY Cassette |
| CZ-03KPL2 | 2-WAY Cassette Fascia (73) | 2-WAY Cassette |
| CZ-P680PJ2 | Branch Pipe – Outdoor (<68kW) | All |
| CZ-P1350PJ2 | Branch Pipe – Outdoor (<168kW) | All |
| CZ-P160BK2 | Branch Pipe – Mini FSV | All |
| CZ-P680BK2 | Branch Pipe – Indoor (<68kW) | All |
| CZ-P1350BK2 | Branch Pipe – Indoor (<168kW) | All |
| CZ-P680PH2 | Branch Pipe – Outdoor (<68kW) | All |
| CZ-P1350PH2 | Branch Pipe – Outdoor (<135kW) | All |
| CZ-P224BH2 | Branch Pipe – Indoor (<22.4kW) | All |
| CZ-P680BH2 | Branch Pipe – Indoor (<68kW) | All |
| CZ-P1350BH2 | Branch Pipe – Indoor (<135kW) | All |
| CZ-SLK2 | Renewal Kit | All |
| CZ-CAPE2 | Solenoid Valve Controller | All |
| CZ-P56HR3 | 3 Pipe Branch Box (<5.6kW) | All |
| CZ-P160HR3 | 3 Pipe Branch Box (<16.0kW) | All |
| CZ-P456HR3 | 3 Pipe Multi Port (4 Ports) Branch Box (<5.6kW) | All |
| CZ-P656HR3 | 3 Pipe Multi Port (6 Ports) Branch Box (<5.6kW) | All |
| CZ-P856HR3 | 3 Pipe Multi Port (8 Ports) Branch Box (<5.6kW) All | All |
| CZ-P4160HR3 | 3 Pipe Multi Port (4 Ports) Branch Box (<16.0kW) | All |
| CZ-P160RVK2 | Gas Pipe Valve Kit | All |
| CZ-P56SVK2 | Solenoid Valve Kit | All |
| CZ-P160SVK2 | Solenoid Valve Kit | All |
| CZ-73DMZ1 | Drain Pump for MZ1 (Optional) | All |
| PANA STOP | Panasonic Safety Tray Overflow Prevention – Float Switch | All |
| CZ-RWRx3 | Wireless Receivers – ALL Models | All |
| VRF CONTROLLERS | |
| Model | Description |
| CZ-ANC2 | FSV On/Off Controller |
| CZ-ANC3 | FSV On/Off Controller |
| CZ-CAPC2 | FSV Interface Adaptor |
| CZ-RTC6BL | CONEX Wired Remote Controller – Bluetooth |
| CZ-RTC5B | Deluxe Wired Controller |
| CZ-RTC4 | Timer Remote Controller (Wired) |
| CZ-RWS3 | Wireless Remote Controller |
Panasonic High Static Ducted Air Conditioners Deluxe Model | Panasonic High Static Ducted Air Conditioners Compact Model | Panasonic Adaptive Ducted Mid Static Compact Single Fan Air Conditioners | Panasonic Adaptive Ducted Deluxe Twin Fan Air Conditioners | Panasonic Ultra Slim Ducted Air Conditioners – Bulkhead
F3 Type Mid Static Adaptive Ducted units are slim and boast excellent performance, making them ideal for installation environments with low ceilings and vertical installations. They also offer the next level of air quality thanks to the nanoe X Generator Mark3, effective even in large spaces.
| INDOOR UNITS – Adaptive Ducted – nanoe™X | ||
| Mid Static | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MF3E5AN | 2.2 | 2.5 |
| S-28MF3E5AN | 2.8 | 3.2 |
| S-36MF3E5AN | 3.6 | 4.2 |
| S-45MF3E5AN | 4.5 | 5 |
| S-56MF3E5AN | 5.6 | 6.3 |
| S-60MF3E5AN | 6 | 7.1 |
| S-73MF3E5AN | 7.3 | 8 |
| S-90MF3E5AN | 9 | 10 |
| S-112MF3E5AN | 10.6 | 11.4 |
| S-140MF3E5AN | 14 | 16 |
| S-160MF3E5AN | 16 | 18 |
M1 Type Slim Low Static Ducted units have a slim design with a height of only 200 mm, making them ideal for small, compact spaces under the ceilings of buildings such as hotels.
| INDOOR UNITS – Slim Low Static Ducted | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MM1E5B | 2.2 | 2.5 |
| S-28MM1E5B | 2.8 | 3.2 |
| S-36MM1E5B | 3.6 | 4.2 |
| S-45MM1E5B | 4.5 | 5.0 |
| S-56MM1E5B | 5.6 | 6.3 |
Z1 Type Slim Low Static Ducted Twenty Series units have a slim design with a height of only 200 mm, making them ideal for small, compact spaces under the ceilings of buildings such as hotels.
| INDOOR UNITS – Slim & Narrow Ducted | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MZ1H4A | 2.2 | 2.5 |
| S-28MZ1H4A | 2.8 | 3.2 |
| S-36MZ1H4A | 3.6 | 4.2 |
| S-45MZ1H4A | 4.5 | 5.0 |
| S-56MZ1H4A | 5.6 | 6.3 |
| S-60MZ1H4A | 6.0 | 7.1 |
| S-73MZ1H4A | 7.3 | 8.0 |
Panasonic VRF/Mini VRF Air Conditioners E2 Type High Static Ducted/High Fresh Air Ducted units offer improved design flexibility in extended duct layouts thanks to their increased external static pressure. They also provide 100% fresh air intake for ventilation (except for S-180ME2E5).
| INDOOR UNITS – High Static Ducted | ||
| Model | Cool (kW) | Heat (kW) |
| S-180ME2E5 | 18.0 | 20.0 |
| S-224ME2E5 | 22.4 | 25.0 |
| S-280ME2E5 | 28.0 | 31.5 |
E1 Type High Static Ducted units are hidden in the ceiling to provide an ideal match for luxury residences and light commercial buildings, offering greater freedom of duct design.
| INDOOR UNITS – High Static Compact Ducted | ||
| Model | Cool (kW) | Heat (kW) |
| S-90ME1R5A | 9.0 | 10.0 |
| S-112ME1R5A | 11.2 | 12.5 |
| S-140ME1R5A | 14.0 | 16.0 |
| S-160ME1R5A | 16.0 | 18.0 |
K2 Type Wall Mounted units boast a stylish design and are compact and lightweight, making them easy to install. Their quiet operation makes them ideal for small offices, hotel rooms, and hospital rooms.
| INDOOR UNITS – Wall Mounted | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MK2E5B | 2.2 | 2.5 |
| S-28MK2E5B | 2.8 | 3.2 |
| S-36MK2E5B | 3.6 | 4.2 |
| S-45MK2E5B | 4.5 | 5.0 |
| S-56MK2E5B | 5.6 | 6.3 |
| S-73MK2E5B | 7.3 | 8.0 |
| S-106MK2E5B | 10.0 | 11.4 |
U2 Type 4-Way Cassette units have a flat design and a built-in drain pump that allows for flexible installation and design options that blend in with interiors and buildings. They also offer the next level of air quality thanks to the nanoe X Generator Mark3, effective even in large spaces
| VRF Indoor – 4-WAY Cassette – nanoe™X | |||
| Model | Cool (kW) | Heat (kW) | Fascia |
| S-22MU2E5BN | 2.2 | 2.5 | CZ-KPU3H |
| S-28MU2E5BN | 2.8 | 3.2 | CZ-KPU3H |
| S-36MU2E5BN | 3.6 | 4.2 | CZ-KPU3H |
| S-45MU2E5BN | 4.5 | 5.0 | CZ-KPU3H |
| S-56MU2E5BN | 5.6 | 6.3 | CZ-KPU3H |
| S-60MU2E5BN | 6.0 | 7.1 | CZ-KPU3H |
| S-73MU2E5BN | 7.3 | 8.0 | CZ-KPU3H |
| S-90MU2E5BN | 9.0 | 10.0 | CZ-KPU3H |
| S-112MU2E5BN | 10.6 | 11.4 | CZ-KPU3H |
| S-140MU2E5BN | 14.0 | 16.0 | CZ-KPU3H |
| S-160MU2E5BN | 16.0 | 18.0 | CZ-KPU3H |
Y3 Type 4-Way Mini Cassette units feature a design compact enough to fit into a 60 × 60 cm ceiling grid with easy installation. They also offer the next level of air quality thanks to the nanoe X Generator Mark3.
| VRF Indoor – 4-WAY Mini Cassette | |||
| Model | Cool (kW) | Heat (kW) | Fascia |
| S-22MY3E | 2.2 | 2.5 | CZ-KPY4 |
| S-28MY3E | 2.8 | 3.2 | CZ-KPY4 |
| S-36MY3E | 3.6 | 4.2 | CZ-KPY4 |
| S-45MY3E | 4.5 | 5.0 | CZ-KPY4 |
| S-56MY3E | 5.6 | 6.3 | CZ-KPY4 |
L1 Type 2-Way Cassette units are very thin, compact, and light, allowing for flexibility in installation. The fan has been redesigned to achieve its size and weight reductions.
| VRF Indoor – 2-WAY Cassette | |||
| Model | Cool (kW) | Heat (kW) | Fascia |
| S-22ML1E5 | 2.2 | 2.5 | CZ-02KPL2 |
| S-28ML1E5 | 2.8 | 3.2 | CZ-02KPL2 |
| S-36ML1E5 | 3.6 | 4.2 | CZ-02KPL2 |
| S-45ML1E5 | 4.5 | 5.0 | CZ-02KPL2 |
| S-56ML1E5 | 5.6 | 6.3 | CZ-02KPL2 |
| S-73ML1E5 | 7.3 | 8.0 | CZ-03KPL2 |
D1 Type 1-Way Cassette units feature a slim design that can be installed in small ceiling spaces. The quiet yet powerful fan blows air to the floor from a ceiling height of up to 4.2 m.
| VRF Indoor – 1-WAY Cassette | |||
| Model | Cool (kW) | Heat (kW) | Fascia |
| S-28MD1E5 | 2.2 | 2.5 | CZ-KPD2 |
| S-36MD1E5 | 3.6 | 4.2 | CZ-KPD2 |
| S-45MD1E5 | 4.5 | 5.0 | CZ-KPD2 |
| S-56MD1E5 | 5.6 | 6.3 | CZ-KPD2 |
| S-73MD1E5 | 7.3 | 8.0 | CZ-KPD2 |
T2 Type Under Ceiling units offer excellent energy-saving performance and comfortable long-distance airflow distribution, making them ideal for stores and schools.
| VRF Indoor – Under Ceiling | ||
| Model | Cool (kW) | Heat (kW) |
| S-36MT2E5A | 3.6 | 4.2 |
| S-45MT2E5A | 4.5 | 5.0 |
| S-56MT2E5A | 5.6 | 6.3 |
| S-73MT2E5A | 7.3 | 8.0 |
| S-106MT2E5A | 10.6 | 11.4 |
| S-140MT2E5A | 14.0 | 16.0 |
P1 Type Floor Standing units have a compact design and are an ideal solution for providing perimeter air conditioning. A standard wired controller can be integrated into the units.
| VRF Indoor – Floor Standing | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MP1E5 | 2.2 | 2.5 |
| S-28MP1E5 | 2.8 | 3.2 |
| S-36MP1E5 | 3.6 | 4.2 |
| S-45MP1E5 | 4.5 | 5.0 |
| S-56MP1E5 | 5.6 | 6.3 |
| S-71MP1E5 | 7.1 | 8.0 |
R1 Type Concealed Floor Standing units are only 229 mm deep and can be easily concealed in the perimeter area for powerful and effective air conditioning.
| VRF Indoor – Concealed Floor Standing | ||
| Model | Cool (kW) | Heat (kW) |
| S-22MR1E5 | 2.2 | 2.5 |
| S-28MR1E5 | 2.8 | 3.2 |
| S-36MR1E5 | 3.6 | 4.2 |
| S-45MR1E5 | 4.5 | 5.0 |
| S-56MR1E5 | 5.6 | 6.3 |
| S-71MR1E5 | 7.1 | 8.0 |
For small-scale commercial and residential use. The Mini-FSV system LE Series is designed for light commercial and residential use with extraordinary energy-saving performance and a high external static pressure of 35 Pa.
| MINI FSV | ||
| Single Phase | ||
| Model | Cool (kW) | Heat (kW) |
| U-4LE2R5 | 12.1 | 12.5 |
| U-5LE2R5 | 14.0 | 16.0 |
| U-6LE2R5 | 15.5 | 16.5 |
| MINI FSV | ||
| Single Phase – Anti Corrosion | ||
| Model | Cool (kW) | Heat (kW) |
| U-4LE2R5E | 12.1 | 12.5 |
| U-5LE2R5E | 14.0 | 16.0 |
| U-6LE2R5E | 15.5 | 16.5 |
| MINI FSV | ||
| Three Phase | ||
| Model | Cool (kW) | Heat (kW) |
| U-4LE2R8 | 12.1 | 12.5 |
| U-5LE2R8 | 14.0 | 16.0 |
| U-6LE2R8 | 15.5 | 16.5 |
| U-8LE1R8 | 22.4 | 25.0 |
| U-10LE1R8 | 25.0 | 28.0 |
| MINI FSV | ||
| Three Phase – Anti Corrosion | ||
| Model | Cool (kW) | Heat (kW) |
| U-8LE1R8E | 22.4 | 25.0 |
| U-10LE1R8E | 25.0 | 28.0 |
Extraordinary energy-saving performance and powerful operation The FSV system ME2 Series is designed for outstanding energy-saving performance, powerful operation, high reliability, and comfort surpassing anything that was previously possible.
| 2-PIPE FSV-EX | ||
| Three Phase | ||
| Model | Cool (kW) | Heat (kW) |
| U-8ME2R8 | 22.4 | 25.0 |
| U-10ME2R8 | 28.0 | 31.5 |
| U-12ME2R8 | 33.5 | 37.5 |
| U-14ME2R8 | 40.0 | 45.0 |
| U-16ME2R8 | 45.0 | 50.0 |
| U-18ME2R8 | 50.0 | 56.0 |
| U-20ME2R8 | 56.0 | 63.0 |
| 2-PIPE FSV-EX | ||
| Three Phase – Anti Corrosion | ||
| Model | Cool (kW) | Heat (kW) |
| U-8ME2R8E | 22.4 | 25.0 |
| U-10ME2R8E | 28.0 | 31.5 |
| U-12ME2R8E | 33.5 | 37.5 |
| U-14ME2R8E | 40.0 | 45.0 |
| U-16ME2R8E | 45.0 | 50.0 |
| U-18ME2R8E | 50.0 | 56.0 |
| U-20ME2R8E | 56.0 | 63.0 |
For simultaneous heating and cooling The simultaneous heating and cooling FSV system MF3 Series is designed to represent the ultimate solution for the most discerning customers and demanding installation environments.
| 3-PIPE FSV-EX | ||
| Three Phase | ||
| Model | Cool (kW) | Heat (kW) |
| U-8MF3R7 | 22.4 | 25.0 |
| U-10MF3R7 | 28.0 | 31.5 |
| U-12MF3R7 | 33.5 | 37.5 |
| U-14MF3R7 | 40.0 | 45.0 |
| U-16MF3R7 | 45.0 | 50.0 |
| VRF ACCESSORIES | ||
| Model | Description | Series Compatibility |
| CZ-KPY4 | 4-WAY Mini Cassette Fascia | 4-WAY Mini Cassette |
| CZ-KPD2 | 1-WAY Cassette Fascia | 1-WAY Cassette |
| CZ-02KPL2 | 2-WAY Cassette Fascia (22 – 56) | 2-WAY Cassette |
| CZ-03KPL2 | 2-WAY Cassette Fascia (73) | 2-WAY Cassette |
| CZ-P680PJ2 | Branch Pipe – Outdoor (<68kW) | All |
| CZ-P1350PJ2 | Branch Pipe – Outdoor (<168kW) | All |
| CZ-P160BK2 | Branch Pipe – Mini FSV | All |
| CZ-P680BK2 | Branch Pipe – Indoor (<68kW) | All |
| CZ-P1350BK2 | Branch Pipe – Indoor (<168kW) | All |
| CZ-P680PH2 | Branch Pipe – Outdoor (<68kW) | All |
| CZ-P1350PH2 | Branch Pipe – Outdoor (<135kW) | All |
| CZ-P224BH2 | Branch Pipe – Indoor (<22.4kW) | All |
| CZ-P680BH2 | Branch Pipe – Indoor (<68kW) | All |
| CZ-P1350BH2 | Branch Pipe – Indoor (<135kW) | All |
| CZ-SLK2 | Renewal Kit | All |
| CZ-CAPE2 | Solenoid Valve Controller | All |
| CZ-P56HR3 | 3 Pipe Branch Box (<5.6kW) | All |
| CZ-P160HR3 | 3 Pipe Branch Box (<16.0kW) | All |
| CZ-P456HR3 | 3 Pipe Multi Port (4 Ports) Branch Box (<5.6kW) | All |
| CZ-P656HR3 | 3 Pipe Multi Port (6 Ports) Branch Box (<5.6kW) | All |
| CZ-P856HR3 | 3 Pipe Multi Port (8 Ports) Branch Box (<5.6kW) All | All |
| CZ-P4160HR3 | 3 Pipe Multi Port (4 Ports) Branch Box (<16.0kW) | All |
| CZ-P160RVK2 | Gas Pipe Valve Kit | All |
| CZ-P56SVK2 | Solenoid Valve Kit | All |
| CZ-P160SVK2 | Solenoid Valve Kit | All |
| CZ-73DMZ1 | Drain Pump for MZ1 (Optional) | All |
| PANA STOP | Panasonic Safety Tray Overflow Prevention – Float Switch | All |
| CZ-RWRx3 | Wireless Receivers – ALL Models | All |
| VRF CONTROLLERS | |
| Model | Description |
| CZ-ANC2 | FSV On/Off Controller |
| CZ-ANC3 | FSV On/Off Controller |
| CZ-CAPC2 | FSV Interface Adaptor |
| CZ-RTC6BL | CONEX Wired Remote Controller – Bluetooth |
| CZ-RTC5B | Deluxe Wired Controller |
| CZ-RTC4 | Timer Remote Controller (Wired) |
| CZ-RWS3 | Wireless Remote Controller |
Panasonic High Static Ducted Air Conditioners Deluxe Model | Panasonic High Static Ducted Air Conditioners Compact Model | Panasonic Adaptive Ducted Mid Static Compact Single Fan Air Conditioners | Panasonic Adaptive Ducted Deluxe Twin Fan Air Conditioners | Panasonic Ultra Slim Ducted Air Conditioners – Bulkhead
