Samsung AM050KXMDEH/EU 14.0kW DVM S Mini Single Fan Outdoor 1 Phase
Samsung AM050KXMDEH/EU 14.0kW DVM S Mini Single Fan Outdoor 1 Phase
14.0 kW Cooling | 14.0 kW Heating
Low Profile | Heat Pump
| Model | AM050KXMDEH/EU | ||
| Power Supply | Ø, V, Hz | 1, 220-240, 50 | |
|
Capacity (Nominal)
|
Rating | HP | 5 |
| Cooling1 | kW | 14 | |
| Heating2 | kW | 14 | |
| Maximum Number of Connectable Indoor Units | 8 | ||
|
Connectable Total Indoor Capacity
|
Minimum | kW | 7 |
| Maximum | kW | 18.2 | |
|
Current
|
MCA4 | A | 27 |
| MFA4 | A | 40 | |
|
k͝ʪθ˝ц k˙ѣʀ̈ʪ͝ʀц ŵɇϩ̈ͱ
|
Cooling1 | W/W | 3.5 |
| Heating2 | W/W | 4.12 | |
|
Compressor
|
Type | Twin BLDC Rotary | |
| Oil Type | PVE | ||
|
Fan
|
Type | Propeller | |
| Quantity | 1 | ||
| ̈θѤͱи ŵɇϩʪ | l/s | 1167 | |
| External Static Pressure | Pa | 29 | |
|
Piping Connections
|
Liquid Pipe | mm/inch | 9.52, 3/8″ |
| Gas Pipe | mm/inch | 15.88, 5/8″ | |
|
Allowable Piping Length
|
Piping Length, Outdoor to Indoor. Maximum (Equivalent) | m | 50 (65) |
| Piping Height. Outdoor Above (Outdoor Below) |
m | 30 (25) | |
| Unit Weight | kg | 83.5 | |
|
External Dimension
|
W x H x D
|
mm
|
940 x 998 x 330 |
| Factory Charge | R410A | kg | 2.5 |
|
Sound3
|
Sound Pressure – Cooling | dB(A) | 55 |
| Sound Pressure – Heating | dB(A) | 57 | |
| Sound Power | dB(A) | 75 | |
|
Operating Ambient Temperature Range
|
Cooling | °C | -5 to 48°C |
| Heating | °C | -20 to 24°C | |
Compact low profile unit ideally suited for apartment installation where the unit can be located on the balcony, with its low unit height and compact footprint it takes up less space of your balcony and minimises obstructions to your view
Description
14.0 kW Cooling
14.0 kW Heating
Low Profile | Heat Pump
