Samsung AM040NXMDGR/EU 12.1kW DVM S Mini Double Fan Outdoor 3 Phase
Samsung AM040NXMDGR/EU 12.1kW DVM S Mini Double Fan Outdoor 3 Phase
12.1 kW Cooling | 12.1 kW Heating
Heat Recovery | Heat Pump
| Model | AM040NXMDGR/EU | ||
| Power Supply | Ø, V, Hz | 3, 380-415, 50 | |
|
Capacity (Nominal)
|
Rating | HP | 4 |
| Cooling1 | kW | 12.1 | |
| Heating2 | kW | 12.1 | |
| Maximum Number of Connectable Indoor Units | 8 | ||
|
Connectable Total Indoor Capacity
|
Minimum | kW | 6 |
| Maximum | kW | 15.7 | |
|
Current
|
MCA4 | A | 16.1 |
| MFA4 | A | 20 | |
|
k͝ʪθ˝ц k˙ѣʀ̈ʪ͝ʀц ŵɇϩ̈ͱ
|
Cooling1 | W/W | 4.5 |
| Heating2 | W/W | 4.8 | |
|
Compressor
|
Type | Twin BLDC Rotary | |
| Oil Type | PVE | ||
|
Fan
|
Type | Propeller | |
| Quantity | 2 | ||
| ̈θѤͱи ŵɇϩʪ | l/s | 1667 | |
| External Static Pressure | Pa | 29 | |
|
Piping Connections
|
Liquid Pipe | mm/inch | 9.52, 3/8″ |
| Gas Pipe | mm/inch | 15.88, 5/8″ | |
| High Pressure Gas Pipe, for Heat Recovery | mm/inch | 15.88, 5/8″ | |
|
Allowable Piping Length
|
Piping Length, Outdoor to Indoor. Maximum (Equivalent) | m | 150 (175) |
| Piping Height. Outdoor Above (Outdoor Below) |
m | 50 (40) | |
| Unit Weight | kg | 95 | |
| External Dimension | W x H x D | mm | 940 x 1,210 x 330 |
| Factory Charge | R410A | kg | 3.2 |
|
Sound3
|
Sound Pressure – Cooling | dB(A) | 50 |
| Sound Pressure – Heating | dB(A) | 52 | |
| Sound Power | dB(A) | 67 | |
|
Operating Ambient Temperature Range
|
Cooling | °C | -5 to 48°C |
| Heating | °C | -25 to 26°C | |
Universal outdoor unit, can be used as a heat pump outdoor or as a heat recovery outdoor. For heat recovery operation, there are no conflict in operation mode requirement, providing simultaneous Heating and Cooling operation when use in conjunction with HR changer and Mode Control Unit (MCU). Connectable indoor units means you can air condition spaces and with precision control to meet your comfort. You can position the outdoor unit away from the indoor unit, so as not to
interfere with your main living space.
Description
12.1 kW Cooling
12.1 kW Heating
Heat Recovery | Heat Pump
