Mitsubishi Electric MSZAP25VGKD2KIT 2.5kW Split System Wall Mounted Air Conditioner
2.5kW Cooling | 3.2kW Heating
Mitsubishi Electric MSZAP25VGKD2KIT 2.5kW Split System Wall Mounted Air Conditioner
Indoor MSZ-AP25VGKD2-A2 | Outdoor MUZ-AP25VGD2-A2
Wireless Controller | Dred Capable System | Built in WIFI
5 Years Manufacturer’s Warranty
| Indoor Unit | MSZ-AP25VGKD2-A2 | |||
| Outdoor Unit | MUZ-AP25 VG(D*5)2-A2 | |||
| Refrigerant | R32 | |||
|
Cooling
|
Capacity [Rated]*1 | kW | 2.5 | |
| Capacity [Min-Max] | kW | 1.10 – 3.60 | ||
| Total Input [Rated]*1 | kW | 0.5 | ||
| Total Input [Min-Max] | kW | 0.21 – 0.99 | ||
| EER | 5 | |||
| AEER | 4.97 | |||
|
TCSPF (Residential)
|
Hot | 7.85 | ||
| Average | 7.31 | |||
| Cold | 7.61 | |||
|
ZERL (Residential) Star Rating*2
|
Hot | 6 | ||
| Average | 5.5 | |||
| Cold | 6 | |||
| Running Current [Rated]*3 | A | 2.6 | ||
|
Sound Pressure Level
|
In [Quiet-Lo-Mid- Hi-SHi] | dBA | 19 – 24 – 31 – 38 – 44 | |
| Out (PWL) | dBA | 46 (59) | ||
| Air Volume (In) [Quiet-SHi] | L/s | 82 – 205 | ||
|
Heating
|
Capacity [Rated]*1 | kW | 3.2 | |
| Capacity [Min-Max] | kW | 1.30 – 5.00 | ||
| Total Input [Rated]*1, 5 | kW | 0.67 | ||
| Total Input [Min-Max] | kW | 0.35 – 1.40 | ||
| COP | 4.78 | |||
| ACOP | 4.75 | |||
|
HSPF (Residential)
|
Hot | 5.48 | ||
| Average | 4.99 | |||
| Cold | 4.59 | |||
|
ZERL (Residential) Star Rating*2
|
Hot | 3.5 | ||
| Average | 3 | |||
| Cold | 3 | |||
| Running Current [Rated]*3 | A | 3.3 | ||
|
Sound Pressure Level
|
In [Quiet-Lo-Mid- Hi-SHi] | dBA | 18 – 25 – 31 – 38 – 42 | |
| Out (PWL) | dBA | 49 (59) | ||
| Air Volume (In) [Quiet-SHi] | L/s | 82 – 190 | ||
| Max. Running Current | A | 7.1 | ||
|
Indoor Unit
|
Input [Rated] (Cooling/Heating) | W | 23/19 | |
| Dimensions [HxWxD] | mm | 299 x 798 x 219 | ||
| Weight | kg | 10.5 | ||
|
Outdoor Unit
|
Dimensions [HxWxD] | mm | 550 x 800 x 285 | |
| Weight | kg | 34.0 (VG)/35.0(VGD) | ||
| Breaker Size | A | 10 | ||
|
Piping
|
Diameter [Liquid/Gas] | mm | ø6.35/ø9.52 | |
| Max. Length/Height | m | 20/12 | ||
|
Guaranteed Operating Range [Outdoor]
|
Cooling | °C | -10 ~ 46 | |
| Heating | °C | -15 ~ 24 | ||
| Refrigerant Amount [Pre-Charged] | kg | 0.7 | ||
Night Mode
Night Mode reduces the brightness of the operation indicator light, disables beep noises, and limits the noise level of the outdoor unit.
R32 refrigerant
R32 enables increased energy efficiency compared to R410A, with just one third of the global warming potential, the risk of environmental harm is greatly reduced.
Blue fin condenser
Anti-corrosion treatment has been applied to the heat exchanger of the outdoor unit. This coating slows the corrosion process of the aluminium fins; this is caused by salt in the air, especially in coastal areas. (Corrosion of the heat exchanger will affect efficiency and performance.)
I-Save Mode
The “i-save” Mode is a simplified setting function that recalls the preferred (preset) temperature at the press of a button on the remote controller. The function ensures the most suitable air conditioning settings are used contributes to reduced power consumption.
Built-In Weekly Timer
Temperature settings and On/Off control can be managed over a period of one week using the Weekly Timer.
Reverse cycle heating
Activate the heating mode to provide a warm and cosy space. Reverse cycle air conditioning can be a relatively efficient and economical way of heating and cooling compared to gas and electric space heaters. Mitsubishi Electric air conditioners are a quiet and clean source of heating for your home.
Full Inverter
The Full Inverter ensures a high level of performance, including the finer control of operation frequency. As a result, improved power management is applied in all heating/cooling ranges and improved comfort is achieved while consuming less energy.
Description
2.5 kW Cooling
3.2 kW Heating
Built In WIFI | Quiet operation
