ActronAir LRE-071CS / LRC-071CS 7.1kW Ultra Slim Low Profile Inverter Split Ducted Air Conditioner

SKU: LRE-071CS / LRC-071CS

7.10 kW Cooling | 7.70 kW Heating
ActronAir LRE-071CS / LRC-071CS 7.1kW Ultra Slim Low Profile Inverter Split Ducted Air Conditioner
Includes Indoor LRE-071CS – Outdoor LRC-071CS | Includes Wired Controller
Indoor 249mm high | Includes Built In Drain Pump | Smooth operator | Gold Coated Protection
5 Years Manufacturer’s Warranty

Or own it from $100.77 weekly for 6 months*

Or pay in slices, no interest ever

Or own it from $100.77 weekly for 6 months*

Or pay in slices, no interest ever

9.5 x 15.88mm (3/8 x 5/8)> Actron Air Conditioning> ActronAir Ducted Air Conditioner Systems> Ducted Air Conditioner Systems> Ultra Slim Low Profile> View All Ducted Systems

Technical Information
OUTDOOR MODEL		LRC-071CS
INDOOR MODEL		LRE-071CS
Nett (Rated) Capacity (kW) (AS/NZS3823.1.2)	Cooling (min – max)	7.30 (2.80 – 8.40)
	Heating (min – max)	7.70 (3.00 – 9.00)
Input Power (kW) (AS/NZS3823.1.2)	Cooling Rated	2.06
	Heating Rated	1.73
1 EER Rated (AS/NZS3823.1.2)	Cooling Rated	3.54
2 COP Rated (AS/NZS3823.1.2)	Cooling Rated	3.54
	Heating Rated	4.45
Power Supply – (V / Ph / Hz)	Outdoor	220 – 240 V / 1Ph+N / 50Hz
Rated Load Amps (AS/NZS3823.1.2)	Cooling	9.1
	Heating	7.4
Full Load Amps (AS/NZS3823.1.2)		16
Circuit Breaker Amps		20
3 Suggested Minimum Mains Cable Size		2.5mm2
3 Suggested Minimum Indoor to Outdoor Power Cable Size & Type		1.0mm2 2 Core + Earth
		1.0mm2 2 Core + Earth
IP Rating	Outdoor	IP24
	Indoor	IPX0
Compressor		Inverter Twin-Rotary
Refrigerant		R32
Airflow Range Indoor (l/s)	High	450
	Medium	370
	Low	300
External Static Pressure Range (Pa)		0 to 160
Airflow l/s	(Min / Nom / Max)	280 / 390 / 500
Outdoor Dimensions (mm)	Depth	342
	Height	673
	Width	890
Indoor Dimensions (mm)	Depth	774
	Height	249
	Width	1100
4 Nominal Weight (kgs)	Outdoor	45
	Indoor	31.6
Indoor Sound Pressure Level (dBA)	(Low / Med / High)	38.5 / 35.5 / 32.5
5 Outdoor Sound Pressure Level (dBA) 1m		60
6 Outdoor Sound Power Level (dBA)		65
Outdoor Operating Range (°C)	Cooling	-15°C to 50°C
	Heating	-25°C to 30°C
	Dry	0°C to 50°C
MEPS Certified		Yes
FEATURES
Wired Wall Controller		WC-03
Follow Me Function		Yes
Sleep		Yes
Turbo		Yes
Auto Defrost Function		Yes
Timer On/Off		Yes
7-Day Scheduler / Weekly timer		Yes
Dehumidification (Dry Mode)		Yes
Return Air Sensor		Yes
External Static Pressure Settings		Yes
Drain Pump		Yes
Bottom Return Air Connection		Optional
Outside Air Intake		Optional
Hanging Brackets		Yes
Hydrophilic Aluminium Coil Protection		Indoor
Outdoor		Yes
Demand Reponse		Ready
Indoor Fan Speed		4-Speed
Outdoor Fan Speed		5-Speed
Auto Restart Auto Power Failure		Yes
Fault Alarm Output Port		Yes
Remote On/Off		Yes
Left-Right Hand Drain Connection – Gravity Fed		Yes
Easyconnect Wi-Fi App		Optional

FIELD PIPING AND CONNECTION
Refrigerant Charge	Factory Charge – (g)	1750
	Refrigerant Charge	20
	Pre-Charge Length – (m)	24
Minimum Field Pipe Length – (m)		3
Maximum Field Pipe Length – (m)		50
Maximum Vertical Height Differential (m) included in max length		30
Field Pipe Size	Liquid Pipe – mm (inch)	9.52 (3/8)
Field Pipe Size	Gas Pipe – mm (inch)	15.9 (5/8)
Outdoor Unit	Liquid Pipe – mm (inch)	9.52 (3/8)
Outdoor Unit	Gas Pipe – mm (inch)	15.9 (5/8)
Indoor Unit	Liquid Pipe – mm (inch)	9.52 (3/8)
Indoor Unit	Gas Pipe – mm (inch)	15.9 (5/8)
Wiring Method		Hardwire to Outdoor
Interconnect Data Cable		2 Core 14/0.20 (0.44m2) Shielded
Interconnect Power Cable		2 Core + Earth

With an ActronAir UltraSlim Series 2 Ducted Split System, you can enjoy the best of both worlds – perfect climate control and energy efficiency. With a height of one of the lowest in its category, it is perfect for homes with limited installation space.

Incorporating DC technology, ActronAir’s UltraSlim Split Ducted range features inverter control and the ability to achieve superior operating efficiency, ensuring optimal comfort all year round.

Features

Indoor

Tailored for tight spaces
The UltraSlim indoor unit hides in the tightest of spaces. At only 249mm high*, it provides maximum comfort with a minimal footprint.
*Applicable to LRE-071CS & LRE-100CS

Easy Installation – Separable Design
ActronAir’s 17kW ducted system has been redesigned. The two-piece construction makes installation into space-constrained roof spaces easier than ever before, while still providing the same level of quality and performance that our customers expect. In addition, the increased airflow variability allows for greater flexibility in room layout, ensuring that you will get the most out of your new air conditioning unit.

Precise airflow
With its high static design, the UltraSlim delivers the required airflow to your space easily, unlike other systems that can struggle and take a lot longer to cool or heat your space.

The extras count
To avoid those annoying extra costs, the UltraSlim comes with many features our competitors don’t include, such as a built-in drain pump, remote on/off and fault alarm outputs for installation ease and efficiency.

Outdoor

Coated Coil Protection
The UltraSlim uses gold fin epoxy coated protection on its indoor and outdoor coils, which helps to reduce corrosion from the harsh Australian conditions, as well as assisting the defrosting process, thus improving heating efficiency.

DC Inverter Technology
The UltraSlim Ducted system uses ultra-energy-efficient DC, or direct current inverter technology in its inverter compressor resulting in improved efficiencies overall, along with optimal cooling performance.

ActronAir LRE-071CS / LRC-071CS 7.1kW Ultra Slim Low Profile Inverter Split Ducted Air Conditioner – Brochure
