Teco Platinum 3D TWS-TSO35C3DVGA 3.5kW Split System Air Conditioner Cooling Only

SKU: TWS-TSO35C3DVGA

Teco Platinum 3D TWS-TSO35C3DVGA 3.5kW Split System Air Conditioner Cooling Only


Model Number Indoor TWS35C3DVGA
Outdoor TSO35C3DVGA
Power supply V – Ph – Hz 220~240 – 1 – 50
Power supply attachment Outdoor
Cooling Capacity (MEPS) kW 3.50 (0.8-4.30)
Running current A 3.7
Power input W 810
E.E.R. rating 4.32
Star rating (zone)
(Hot/Med/Cold)
6 / 5 / 5.5
Moisture removal L/Hr 1.0
Indoor fan speeds Turbo/
H/M/L/Silent
5
Indoor cooling air flow (max) L/ 236
Compressor type Rotary
Indoor sound power level dB(A) 59
Outdoor sound power level dB(A) 54
Refrigerant type R32
Connection pipe size
(Liquid / Gas)
mm (inch) 6.35 / 12.7 (1/4? / 1/2″)
Max. pipe length m 20
Max. height difference m 10
Pipe connection method Flare
Indoor dimensions
(H x W x D)
mm 316 x 940 x 224
Indoor net weight Kg 12.0
Outdoor dimensions
(H x W x D)
mm 545 x 800 x 315
Outdoor net weight Kg 28
Ambient temperature
(Cooling / Heating)
°C 16~52 / -15~32

Description

3.5 kW Cooling
Built-in WI-FI | R32
PM 2.5 Filter | 3D Airflow
